Court Cover Systems
Court Cover Systems

Arched Laminated
Wood Frame

Glulam arch structure with PVC canopy
The warmth of timber. The strength of engineering.

30 m

Max clear span

50+

Year design life

GL28h

Glulam class
Request
SpecificationsDownload
Brochure
01 — Product Overview

Engineered for
the long game.

Our glued laminated timber (glulam) arch system is the premium choice for facilities where natural aesthetics matter as much as Structural performance. Each arch is manufactured from European spruce laminations, pressure-bonded to GL24h or GL28h strength class, then CNC-cut to the precise geometry of your site.
The PVC membrane canopy — tensioned over galvanised purlins — provides full weather protection rated to EN 13561. UV-stabilised and anti-algal, the membrane is available in a range of translucencies to balance daylight and glare.
Included as standard
✓ Structural calculation package
✓ CE declarations for all components
✓ 3D visualisation renders
✓ Permit documentation support
✓ Site installation crew
✓ As-built drawings
✓ Maintenance manual
✓ 12-month workmanship guarantee
02 — Key Features

Built with purpose
at every level.

Every detail of this system is resolved for long-term sports facility use — not general construction.

Column-Free Interior

Arched geometry eliminates all internal columns, giving players the full court footprint without obstruction.



50+ Year Design Life

Glulam arches treated and sealed to EN 335 Hazard Class 3 for exposed outdoor use. No structural maintenance cycles.




Weather-Sealed Envelope

PVC canopy tensioned and sealed at all purlins with EPDM gaskets. Zero water ingress under certified test conditions.




Fully Custom Geometry

Span, pitch, ridge height, and bay count all vary to match your site. CNC-cut arches ensure ±2 mm accuracy at manufacture.




Fast Site Assembly

Pre-cut and pre-drilled components arrive flatpacked. A standard two-court cover is erected in 8–12 working days.




12-Month Guarantee

All workmanship and materials warranted for 12 months from handover. Extended service plans available on request.



03 — Technical Specifications

Numbers that matter
to engineers.

FRAME MATERIAL
Glued laminated timber (glulam)
Strength class
GL24h / GL28h (EN 14080)
Max clear span
Up to 30 m
Bay spacing
4 – 6 m (standard)
Foundation
Pad footings or ground screws
Membrane type
PVC coated polyester, 900 g/m²
UV rating
UV-stabilised, Class 1
Translucency
5 % – 25 % (selectable)
Snow load
Engineered to site location
Wind load
Up to 140 km/h sustained
Ridge height
From 6.5 m (varies with span)
Eave height
From 3.2 m
Length
Modular — any multiple of bay spacing
Gable treatment
Open, PVC panel, or polycarb
Timber treatment
GL surface planed + impregnated
Membrane colour
White, cream, grey, custom
Guttering
Aluminium valley + eave gutters
Lighting provision
Purlin-mount brackets included
04 — Project Gallery

Installed & operating.

Interior — clear span, unobstructed court
05 — Project Delivery

One partner.
Every phase.

Every detail of this system is resolved for long-term sports facility use — not general construction.
Step 1

 Site Survey

Topographic survey and site assessment. Load combination calculations begin immediately.


Step 2

Concept Design

Preliminary layout drawings and 3D visualisations for stakeholder approval. Budget estimate issued.



Step 3

Permit Documentation

Full structural calculation package prepared for local authority submission. CE declarations included.



Step 4

Manufacture

Components fabricated to approved drawings. Factory hold-point inspection available to client.



Step 5

Installation

Our site crew erects the structure. Daily progress reports. Site manager on-site throughout.



Step 6

Handover

Snagging completed, as-built drawings issued, maintenance manuals supplied. 12-month guarantee starts.



START YOUR PROJECT

Ready to build?
Let's talk.

Tell us about your site and timeline. We will prepare a concept layout and budget estimate within 5 working days — free of charge.
